Burning Lead, 100', 1/0 Cable,3/8"Hose,Ends,BR-22

UNDERWATER 1/0 BURNING LEAD, 100' (BL-1)

Divers Supply's BL-1 burning lead is constructed of 1/0 weld cable and Gates 33HB.375 taped with 2” wide high grade black duct tape, approx. 8 to 10 inches apart, the full length of the assembly. The working end is equipped with a Broco BR-22 underwater cutting torch. The surface end is terminated with a cable lug on the cable and a reusable, brass oxygen (O2) fitting on the hose.

While this is our standard configurations, we can make custom burning leads of different lengths, cable gauge and torch to meet your needs - just give us a call!

BL-1 Specifications:
Length: 100' (30m)
1/0 Welding Cable: ASTM B172 rope stranded copper conductor insulated with elastomer rubber hybrid compound.
Gas Hose: Gates 3/8” I.D. (33HB.375) Dive Master diver's breathing gas hose.
Torch: Broco BR-22 underwater cutting torch.
Weight: 70 lb (32 kg)

Welding Cable Specifications: Gauge: 1/0 Conductor: ASTM B172 Rope stranded copper Voltage Rating: 600V (intermittent use, up to 3 hours continuous) Separator: Vinyl Insulator: Oil and water resistant elastomer rubber hybrid compound Safety Liner: Visible under the outer jacket, so you can see any cuts, nicks or excessive wear Temperature Range: -49°F to 105°F (-45°C to 40°C) Stranding #: 1064 Stranding Construction: 19 x 56 / 30 Conductor I.D.: 0.397" (10mm) Finished I.D.: 0.61" (15.5mm)

Gas Hose Specifications:
Description Gates 3/8” I.D. (33HB.375) Dive Master diver's breathing gas hose.
Inner Diameter 3/8" (9.5 mm)
Outer Diameter: 0.75" (19.1 mm)
Maximum Working Pressure: 1125 psi (77.6 bar)
Minimum Bend Radius: 4.0" (102 mm)
Temperature Range: -20°F to 120°F (-29°C to 49°C)
Tube: Type C (Nitrile), Black
Reinforcement: Braided, high tensile synthetic textile cord
Cover: Type A (chloroprene), black, perforated
Design Factor: 4:1
Weight: 0.19 lb/foot (283 g/m)
Standards: Meets BS EN250:2014
Cleanliness: At the factory, the length of hose is rinsed with water for 30 seconds to 1 minute, followed by a sponge plug blown through the hose to remove water. As second, alcohol soaked sponge is then blown through the hose. followed by air for 30 seconds.
